Aeris MIRA - Model Pico Mobile LDS -Natural Gas Leak Detection System w/GPS
Locate Natural Gas Leaks with Unmatched Sensitivity, Precision and Thermogenic vs. Biogenic Discrimination Introducing the new MIRA Pico Mobile LDS, a high sensitivity natural gas leak detection system from Aeris Technologies, Inc. The Pico Mobile combines a breakthrough, real-time laser absorption spectrometer with built-in GPS capability to produce the Worlds smallest, most powerful leak-mapping tool.
The Pico Mobile LDS operates in the mid-IR, achieving unparalleled, simultaneous methane and ethane sensitivity at the 1ppb/s level. Natural gas is unambiguously discriminated from other, biogenic sources such as landfill gas, cattle operations, swamp gas, and permafrost. This unique capability provides a discrimination capability 30 times greater than that of other laser-based analyzers at 1/10th the size, reducing false alarms and enabling accurate ethane/methane ratio data in real-time. Pico Mobile LDS systems provide accurate ethane/methane ratios at levels rivaling mass spectrometric methods, without associated sample handling or consumables.
- Unmatched <1ppb/s sensitivity for CH4 and C2H6
- 30x better ethane sensitivity than competing systems
- Portable, handheld operation- 6 hr. battery
- 1 or 2Hz operation
- High accuracy GPS, magnetically mounted antennae
- Wifi, RS232, streaming capability
- 10x + smaller and lighter than competition
- Low 15W power consumption
- Robust optical platform: 100x more optically robust than competing ”cavity-based” systems
- Water vapor measured to report dry mole fractions
- Data formatted for viewing in Google Earthtm
