Asoe Hose Manufacturing Inc.

ASOEModel LONGMAN 600 -NBR Frac Water Layflat Hoses

SHARE

Construction: Circular polyester weave extruded internally and externally with NBR-PVC. Hose shall be made from 100% high tenacity synthetic yarn circular woven and completely, protected and locked-in by tough highly resistant synthetic nitrile rubber, forming a single homogenous construction without the use of glues or adhesives of any type.

Most popular related searches
  • a. Ultimate Tensile Strength: Tensile strength of the lining and cover shall not be less than 1500 psi (10,500 kpa ).
  • b. Ultimate Elongation: 400% minimum.
  • c. Accelerated Aging Test

The tensile strength and ultimate elongation of the vulcanized rubber compound which has been subjected to the action of oxygen at a pressure of 300 psi +/- 10 psi , (2100kpa +/- 70kpa) and temperature of 70 degrees centigrade +/-1 degree centigrade (158 F +/- 18 F ) for a period of 96 hours shall be , greater than 60% of the original properties stated.

  • Color:Black ribbed
  • Temperature range:From -20 C deg to 80 C deg (-4 F deg to 176 F deg)
  • Elongation at WP:<1.5%
  • Expansion at WP:<6%
  • Abrasion:6000 DIN cycles
  • Standard Length: 660ft

Applications: Suitable for use and recommended for INDUSTRIAL and AGRICULTURE applications in:

  • Dewatering and operations
  • Frac water transfer
  • Refineries & chemical plants-(Resists Aromatics), Oils, Medium and Heavy Hydrocarbons, Diesel Fuels & Many Chemicals In Solution
  • Liquid Transfer Water, Liquid Manure, Industrial Sludges & Slurries, Contaminated Liquids, Fertilizers,
