NeoChem - Model 20 -Fully Automated Benchtop or Standalone Biochemistry Analyser

NeoChem 20 is a fully automated biochemistry analyzer with an extremely accurate optical system comprised of fiber optic and high resolution filters. On-board 24h non-stop reagent cooling system ensures the maximum utilisation of the reagents. Durable ceramic syringes provide high accuracy and precision. Highly intelligent software can manage up to 20 virtual sample trays, so that 1080 samples can be edited simultaneously. This potent system with 71 sample positions for routine samples, standard positions, QC positions and STAT option gives you great comfort in work, whether you use it as a benchtop or standalone analyzer.

• Testing speed Up to 210 tests/hour
• Assay method End Point,  2-Point End Point,  Rate (Kinetic method),  2-Point Rate
• Bichromatic, Blank (Reagent & Sample Blank), Immunoturbidimetry
• Calibration mode Linear calibration:          Single point,  Multiple point  ( up to 8 point)
• Non-linear calibration:  Logit-Log 4P,  Logit-Log 5P,  Line Graph,
• Exponential 5P, Weibull,  Spline.
• Reagent tray 60 position (30 x 20 ml and 30 x 50 ml bottles) on removable tray
• Reagent volume Range 5 – 500 µl  in 0,5 µl step
• Sample tray 71 Positions for tubes or sample cups, includes routine samples,
• standard, QC and STAT samples
• Sample volume range  2 – 100 µl   in 0,1 µl step
• Reaction tray 120 reusable plastic cuvettes in 6 segments (7 mm optical path)
• Reaction volume 150 – 900 µl
• Reaction temperature 37 ± 0,1 ?
• Reagent  temperature From 2 – 8 ?
• Photometer 10 wavelengths: 340, 405, 450, 492, 510, 546, 578, 630, 700, 800 nm
• Static array spectrophotometric system with high resolution filters
• Abs linearity from -0,5 Abs up to 6,0 Abs with resolution 0,0001 Abs
• Wavelength accuracy  ± 1 nm
• Light source 12V / 20W long life halogen lamp
• Interface RS232 (instrument-PC),   LIS supported
• Water consumption Up to 4 lit/hour
• Alarms “Distilled water empty”,  “Detergent empty”  and  “Waste full”
• QC Rules Multi QC function. For every test up to 3 different QC materijal
• Other features On-board mixer, Low water consumption, Automatic cuvette detection and selection, Minimal maintenance.
• Monitoring instrument status in real time, remaining volume of reagents, reaction curve, results…
• Dimensions 730 x 890 x 1120 mm (WxDxH),  weight 83 kg
