Atlantic Boss - Model 50102/04 -No Return Valve Combo/Metal
The installation of an Explosion Isolation device on all suction side ducts that transport material with a Kst value above zero is an NFPA Requirement.
Most popular related searches
energy management system
explosion isolation
spark detection
epoxy coating
baghouse filter
spark detection system
metal dust
worker protection
EN standard
baghouse
Installing a No Return Valve Combo/Metal will protect workers and facilities from the damaging effect of a baghouse or filter explosion.
The No Return Valve Combo/Metal is designed for use with all EcoMAXX® High Speed Abort Gates, Fire Break Shutters, Raptor Spark Detection & Extinguishing/Suppression Systems, and Energy Management Systems.
- EN 16447
- NFPA 69
- ATEX Certified; NFPA 69 Compliant
- Heavy Duty Welded Steel Construction
- Epoxy Powder Coated Safety Red Finish
- Flanged Inlet and Outlet with Co-Flanges
- Grounding Lugs
- Locking Mechanism
- Class ST 3 Applications
- Kst max: 325 bar m/s
- Pred max: 1.0 bar (4”-7”) 0.6 bar (8”- 36”) 0.5 bar (40”- 48”)
- Certification EN 16447
- Metallic and organic dusts
- Class ST 3 Applications
- Kst max: 400 bar m/s
- Pred max: 1.0 bar (8”-16”) 0.6 bar (22”)
- Certification EN 16447
