Triple D Pump - Non-Clog Pump Lift Stations
Non-Clog lift stations are used when the customer has a need for higher flow, and has a lower head pressure. Many cities and municipalities use our non-clog lift stations, as they are far more cost effective than gravity sewer systems.
Triple D Pump Company can design a Non-Clog Pump Lift Station tailored to your flow and solids-handling requirements. Systems are available in simplex, duplex, or triplex configurations with wet wells ranging from 24" diameter x 36" deep to 12` diameter x 30` deep. Our Non-Clog Pumps are capable of passing 3" solids. We offer:
-
Pump sizes from 3 HP to 100+ HP, depending on head and flow requirements
-
Voltages including 208, 230, 460, and 575, in single-phase or three-phase
-
Explosion-proof motor options (Class I, Division 1, Groups C & D)
-
Corrosion-resistant coatings and epoxy-lined basins
-
Attached or separate valve vaults with check and plug valves
-
Heavy-duty, stainless steel guide rail systems for easy maintenance access
-
Control panels with manual/automatic operation, alarms, VFDs, and SCADA-ready features
All systems are factory-tested and can be delivered assembled to the job site for quick installation and startup.
-
Passes Large Solids with Ease – Impellers handle solids up to 3″ or more
-
Minimizes Clogs and Downtime – Ideal for large solids, and high-flow environments
-
Built for Demanding Conditions – Corrosion-resistant materials and rugged construction
-
Customizable for Any Site – Flexible layouts, power options, and controls
-
Available in High Horsepower Ranges – Up to 100+ HP for major municipal systems
-
Explosion-Proof and Chemical Resistant Options – Safe for tough industrial applications
-
Delivered Assembled – Reduces install time and field labor
-
Controls Available – Controls compatible with VFDs, telemetry, and SCADA-ready panels
