Pro-Uni - Model UA-8~10 -Normally Closed Type Solenoid Valve
FromPro Uni-D Co Ltd
UA series is direct-acting, conductive, and normally closed (NC) 3/2 way solenoid valve. Availability of fluid type:water, air, vacuum
Able to be operated directly without pressure. Applicable for exhausting facility, ex:Air cylinder after power-off. Acceptable for customizeation-Viton (130?) plug.
Most popular related searches
CAUTIONS:
- Before pipelining, the pipe line must be very clean without any contaminants or any other things not ought to be existed.
- To prolong the life time of the product, Y-line filter should be installed in the front end of solenoid valve.
- AC voltage tolerance:±10%;DC voltage tolerance:±1%
- It should be installed horizontally;vertical installation is not advisable.
Not Suitalbe For Fluid As Below:
- Liquid status when it is high temperature;solid status when it is cool.
- Corrosive fluid
- Viscosity over 20cst
