Pro-Uni - Model UD-6NO~10NO -Normally Open Type Solenoid Valve
FromPro Uni-D Co Ltd
UD-NO series is direct-acting, conductive, and normally closed (NC) 2/2 way solenoid valve. Able to be operated directly without pressure. Availability of fluid type:water, air, light oil, gas, vacuum. Acceptable for customizeation:Viton (130?) , Silicone (130?) and EPDM (130?).
Most popular related searches
solenoid valve
solenoid lever valve
servo-controlled solenoid valve
corrosive fluid
pipe lining
valve operator
CAUTIONS:
- Before pipelining, the pipe line must be very clean without any contaminants or any other things not ought to be existed.
- To prolong the life time of the product, Y-line filter should be installed in the front end of solenoid valve.
- AC voltage tolerance:±10%;DC voltage tolerance:±1%
- It should be installed horizontally;vertical installation is not advisable.
Not Suitalbe For Fluid As Below:
- Liquid status when it is high temperature;solid status when it is cool.
- Corrosive fluid
- Viscosity over 20cst
