Obsta - Model HI STI-240V -Cold Neon Discharge Low Intensity Light
FromObsta
The OBSTA HI STI is devoted to the marking of all kinds of obstacles such as buildings, airports, broadcast towers etc. The OBSTA HI STI is a one piece moulded assembly which includes a constant power converter and the proper discharge lamp (13 turns). The OBSTA HI STI P/N113110 has no requirement for a ground connection, which avoids any voltage return from the earth (for example due to lightning). However in intense electromagnetic fields (radiant poles, multi directional radio antennas), it is recommended to use the OBSTA HI STI APR P/N113113.
Most popular related searches
- Perfectly waterproof with hard glass cover
- Great light efficiency
- Large vertical beam spread exceeding FAA and ICAO standard
- No grounding issue, class II,
- Protected against transient overvoltages
- Alarm by closing relay in case of lamp failure or low power supply
- Weight 3,1kg
- Operating temperature -30/+60°C
- IP degree IP66
- Size of the light 247mm (height) x 140mm (over diameter)
- Wiring On 4 stripped wires 4x1,5mm² (lenght of cable 1 meter) (2 power wires, 2 alarm wires)
- Attachment 2 screws type M8 (provided) horizontally. Thikness to screw into : 1 up to 5 mm
- Life time 10 years
- Power supply 6 W
- Current drawn 500 mA
- Power supply 12VDC (-10%; +15%)
