Cubic Instruments - Model Gasboard-2108 -OEM Modules Gas Analyzer
Gasboard-2108 is Cubic Instruments new generation NDIR Gas Bench which detects CO, CO2, HC (with quad infrared detectors), and NO (with micro-flow NDIR detector) simultaneously with the innovative one gas cell design.Cubic-Ruiyi Gas Modules Gasboard-2108 series is suitable for automobile exhaust emission monitoring and environmental monitoring, meeting gasoline vehicles emission measurement standard of GB 18285-2018.
Adopting the high-precision dual-beam infrared gas analysis technology of independent intellectual property rights to measure the concentration of CO, CO2, and HC, and the international PCT patent (PCT/CN2018100767) micro-flow infrared dual-gas chamber technology to measure the concentration of NO, the Gasboard-2108 has good anti-interference and high accuracy performance.
Infrared dual-gas chamber technology is an advanced measurement methods. The measured gas and the reference gas are in separate two chambers. When the infrared light source irradiates the measured gas and the reference gas respectively, the signal waveform formed by detector is passed through the signal processing system to obtain the measured gas concentration through the ratio value.
▪ Four gases HC, CO, CO2, NO detection with one sensor bench.
▪ Combine the traditional NDIR and micro-flow NDIR with one infrared source and gas chamber.
▪ Micro-flow NDIR replaces the electrochemical NO sensor and results into less maintenance cost and fast response.
▪ Supports long lifetime electrochemical or zirconia O2 sensor connection.
▪ Automatic temperature and pressure correction.
▪ High accuracy and stability.
▪ Compact structure, modular sensor design, easy to integrate.
- Emission gas analyzer manufacturer
- Exhaust gas analysis equipment integrator
