Lev-Co - Model MPH10 - 1000 CFM -11-004 -Oil Mist Collector

The system is best suited for capturing applications that include metalworking, cutting, forming, and shop environments across multiple industries.

The unit comes with self-draining filters and has a horizontal profile. It includes the new removal bottom sump with a 3/4" drain, mounting angles to hang or surface mount, and an 8" bottom inlet. It features a 1" polyester pre-filter, a 4" MERV 14 primary filter, and a 1 HP BI blower TEFC motor.

Typically, these units are directly mounted to machines horizontally for direct capture of contaminants and can be suspended from any suitable roof support strut.

Main Options:

• Fan/Motor Upgrades or Options
• Preventative maintenance pressure gauges
• Variable Frequency Drives

• Includes filter access door on each side for left or right-hand applications
• Acoustically lined blower cabinet
• Max Door Opening: 14 ft ²
• Ultra-Seal® filter mounting system
• Three Phase Motor

Specifications:

• Construction: 16/18 Gauge welded steel cabinet with powder-coat finish
• Blower Pkg (HP): 1 HP
• Noise Level (dBA): 75 dBA
• Electrical: 115/1/60, 12 Amps
• Nominal Air Flow (CFM): 1000

• 95% Collection Efficiency at 1 to 4 Microns:Designed specifically for oil mist, the MistPlus® II filter provides up to 95% filtration efficiency of 1 to 4 micron mist droplets. The proprietary, V-shaped filter design aids in drainage of collected mist; extending filter life.
• Sealed Cabinet Construction:18 gauge steel, seam-sealed cabinet eliminates contaminant escape common with stitch-welded or bolt-on panel designs.
• Lever locking Filter Placement System:Ensures quick and accurate filter replacement; eliminates contaminant bypass of filters, reduces equipment and facility maintenance.
• Low-profile Cabinet Design:Horizontal orientation allows for installation directly above the machine tool-even in low ceiling applications; saves floor space.
• Superior Liquid Drainage:10-inch bottom inlet and 2-inch deep sump enable high-volume, 24-hour, 7-day operation; no manual handling of liquids.
• Extended Filter Life, Reduced Maintenance:MistPlus® II filter design reduces dirt loading and filter maintenance; extending filter life up to two years.
• Direct-Drive Blower:Energy-efficient; superior air flow and higher static pressure operation; no belts or pulleys to replace, acoustic-lined cabinet.

Top 5 contaminants/processes/applications:

• Grinding sparks
• CNC Machining
• Lathe Work
• Aerospace Machining
• Cold Heading of Metals

Don`t see your contaminants? Give us a call! 1-888-862-5356 or Click our instant chatbox.

IMPORTANT: For your Health and Safety, make sure to talk to an application engineer before purchasing.

MPH10-500-1

500CFM source capture mist collector with:

• (3) MIST-PLUS II main filter with (2) MERV14 pleated synthetic, washable filters (17.5 x 18.5 x 3.75)
• 1/2 HP 115/1/60 Hz
• 77.5 dBA, with rubber vibration insulator and 10 collar on bottom

AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

MPH-10-1000-1

1000 cfm source capture mist collector with:

• (3) MIST-PLUS II main filter with (2) MERV14 pleated synthetic, washable filters (17.5 x 18.5 x 3.75)
• 1 HP 115/1/60 Hz
• 77.5 dBA, with rubber vibration insulator and 10 collar on bottom.

AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

MPH10-1000-2

1000 cfm source capture mist collector with:

• (3) MIST-PLUS II main filter with (2) MERV14 pleated synthetic, washable filters (17.5 x 18.5 x 3.75)
• 1 Hp 208-230/460/3/60 Hz
• 77.5 dBA, with rubber vibration insulator, and 10 collar on bottom.

AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

MPH-10-1000-3

1000 cfm source capture mist collector with:

• (3) MIST-PLUS II main filter with (2) MERV14 pleated synthetic, washable filters (17.5 x 18.5 x 3.75)
• 1 HP 575/3/60 Hz
• 77.5 dBA, with rubber vibration insulator and 10 collar on bottom.

AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

• Replacement Filters
• Preventative Maintenance Pressure Gauges (when ordering main unit)
• Variable Frequency Drives
