Olfasense - Acetone Comparative Scale
The Acetone Comparative Scale by Olfasense is a comparative scale in accordance with ISO 16000-28, as well as ISO 16000-30 and VDI 4302, for the controlled presentation of concentrations of acetone in air for the purpose of a comparative estimation of odour intensity.
The 16 different concentrations (PI scale 0 -15) are created through the dosing and evaporation of liquid acetone into an open jet of the carrier air and presentation to the panel members by means of a glass nose funnel.
The Acetone Comparative Scale satisfies the requirements of ISO 16000-28 , as well as ISO 16000-30 and VDI 4302, and allows the creation of the 16 levels after a free selection of the panel member.
Liquid acetone is required for the operation of the Acetone Comparative Scale. By calibrating the device with a suitable monitor (e.g. FID), the user can set it to the desired PI levels.
The Acetone Comparative Scale consists of a housing with a touch display as a user interface and a nose funnel for presenting the sample to the test person.
Standards
The Acetone Comparative Scale is fully compliant with
- ISO 16000-28
- ISO 16000-30
- VDI 4302 Part 1
- 100% compliant to ISO 16000-28, ISO 16000-30 and VDI 4302 Part 1
- High accuracy of acetone concentrations
- Low room air contamination
- 16 different concentrations (PI scale 0 -15)
- Compact/transportable
- Low gas consumption
