VZORModel MARK-509 -On-line dissolved hydrogen meter

FromVZOR
SHARE
MARK-509 is a dual-channel analyzer for continious measurements of dissolved hydrogen concentration (including low-level concentrations) and temperature for water and aqueous slutions.
Most popular related searches
  • Two independently operated channels
  • Convenient and accurate measurements
  • Automatic barometric pressure and temperature compensation
  • Easy and fast calibration
  • Long-lived probe: operates for up to 10 years
  • Probe cable length up to 100 m
  • IP65 rated for waterproof and dustproof applications
  • The large backlit graphic LCD shows the measured value and units, temperature, time, date, battery life and menu options
  • Temperature, °C : 0-70
  • Speed of water flow through stabilization module, dm3/ min : 0.07-5
  • Speed of water flow at hydraulic panel input, dm3/ min : 0.08-5



  • meter
  • DH probe with 5 m cable
  • electrolyte
  • hydraulic panel or stabilization module
  • probe maintenance kit
  • calibrator
  • operation manual
  • second channel DO probe with 5 m cable
  • hydraulic panel or stabilization module
  • extension cable up to 95 m
