Real Tech - Model M Series -Online UV254 Organics Water Analyzer
Real Tech’s online UV254 / UVT analyzer provides rapid real-time measurement of organic matter in water or wastewater output as UV254 (cm-1) or UV transmittance / UVT (%). The UV254 analyzer utilizes light at a 254 nm wavelength as most organic compounds, specifically aromatic organics, absorb light at this wavelength. Benefiting from our innovative Ortho-Beam and Split-Sense Pro technologies, accurate and reliable measurements are output for the highest level of confidence in organics monitoring. Continuous organic monitoring can bring significant value to many applications including UV disinfection performance and efficiency, coagulation dose optimization, DBP formation potential, source water monitoring and so much more. Parameter(s): UVT, UV254.
- Practical, accurate and affordable
- Real-time UVT or UV254 organics monitoring
- Patented technology provides superior measurement performance
- Operator friendly, low maintenance design
- Wastewater to high purity measurement ranges
- 4 line x 20 character backlit LCD display
- Innovative custom calibration feature
- Simple to install and easy to operate
Characteristic: Technical Data
- Path Lengths: 1 mm, 2 mm, 4 mm, 8 mm, 10 mm x 20 mm, 50 mm, 100 mm, 150 mm, 250 mm
- Parameters: UVT, UV254
- Accuracy: ± 0.5% FS
- Units: % or cm-1 (mg/L correlated value)
- Sampling Time: 10 seconds
- Calibration: In-situ zeroing to any sample with known UVT. No further calibration required.
- Cleaning: In-situ cleaning makes cleaning quick and easy. Automatic chemical cleaning is optional.
- Self-Diagnostic: Detection and diagnosis of internal system fault
- Operator Interface: Five push buttons to control a comprehensive hierarchical menu system
- Display: 4 line x 20 character backlit LCD with LED alarm indicator
- Alarms: Dry contact terminals allow operator configurable alarms for: high and low UVT/UVA set points, low lamp output, leak detected, system fault, etc.
- Humidity Control: Humidity sensor with large regeneratable desiccant system
- Outputs: Self-powered 4-20mA, RS232 serial for PC
- Wavelengths: 253.7 nm (optional 550 nm turbidity compensation upgrade)
- Light Source: Low-pressure mercury UV lamp
- Lamp Life: 2 years
- Flow Rate: 300 - 1000 mL/min
- Pressure Rating: 20 PSI maximum
- Fluid Connections: 1/4" OD tube push-in fittings
- Electrical: 24VDC 40W power adapter (accepts 90-250VAC 50/60Hz)
- Storage Temp: -20 to 60°C (-4 to 140°F)
- Operating Temp: 0 to 45°C (32 to 113°F)
- Enclosure: NEMA 4X, wall mountable
- Weight: 22 lb (M2000 series & M3000) or 24 lb (M4000 series)
- Dimensions: 17”H x 14.25”W x 7.5”D (M2000 series & M3000) or 17.75”H x 15.5”W x 6.75”D (M4000 series)
- Technology: Ortho-Beam and Split-Sense Pro
- Warranty: 2-year limited warranty (Extended care packages available)
- Analyzer Upgrades: Turbidity Comp. Upgrade, High Temp. Upgrade I, High Temp.
- Upgrade II, Cellular Modem, Dual Transmitter
* Technical Specifications are subject to change without notice.
