Lanry - Model UOL Series -Open Channel Flowmeter
UOL serials is non-contact ultrasonic open channel flow meter, with low blind area, high sensitivity, high stability. It consists of ultrasonic probe and the host, mainly used for measuring water conservancy irrigation, sewage plants, enterprises and institutions of the flow rate of the sewage outfalls, urban sewage and chemical enterprise part of the flow measurement.
Most popular related searches
open channel flow meter
channel flow meter
open channel flow
ultrasonic open channel flow
flow meter
open channel meter
weir rectangular
ultrasonic probe
level monitoring
sewage plant
- Not contact liquid measure, easy to maintain.
- High accuracy, 1mm for level measure.
- Match with various weir and flume, Parshall flume, Right-angle triangle weir, rectangular weir, groove, and throat channel slot.
- Large screen display, double line 14 bit LCD liquid crystal display (with backlight).
- Automatic temperature compensation, automatic filtering system, strong anti-jamming.
- 4-20MA, Hart, RS485 ( modbus ) can be optional.
- High protection grade, transmitter is IP67, sensor is IP68.
- 6pcs relay, can be set high, low and fault alarms.
