Oventrop GmbH & Co. KG

- Model PN 16 - Ball valves with Lever

From

0

Brass, nickel plated, full flow.  Ball made of chrome plated brass, PTFE seats, O-ring seal. Nominal pressure PN 20 for cold water.
Lever made of galvanised steel with plastic coating.  B
oth ports female thread.  Material: Brass. Surface: nickel plated.

  • kvs: 5.6
  • Size: DN 8
  • max. operating pressure: 16 bar
  • min. operating temperature: -10 °C
  • max. operating temperature: 100 °C
  • Item no.: 1076002
  • EAN: 4026755128840
  • Manufacturer: Oventrop GmbH & Co. KG
  • Subject to technical modifications without notice.
