Verderflex Vantage - Model 5000 SCADA LV -Opto-Isolated Remotely Controlled Cased Drive Tube Pump
The Verderflex Vantage 5000 SCADA LV is the next generation in 24V DC opto-isolated remotely controlled cased drive tube pumps combining precision dosing and dispensing accuracy with high discharge pressures, an intuitive touch screen user interface and a USB data backup port. Ideal for SCADA systems, control signal inputs & outputs include 0-10V, 4 to 20mA & proportional flow modes, 7 control volt free inputs & 4 volt free status outputs.
Most popular related searches
cased tube pump
tube pump
peristaltic cased tube pump
pump tubing
mineral processing
pharmaceutical water
precision dosing
SCADA system
water treatment
chemical dosing
- I/O Protection: Opto isolated 24V DC
- Max. flow rate: 6600 ml/min
- Max. (discharge) pressure: 7 bar
- Turn down ratio: 4096:1
- Protection Standard: IP66 & NEMA 4X
- Display & Programming: Intuitive 110mm Full Colour Touch Screen LCD
- Dosing Program Backup: USB v2 dataport
- Analogue Input rating: 0-10V, 4-20mA, Frequency
- Analogue Outputs rating: 0-10V, 4-20mA, Frequency
- Number of Control Inputs: 7
- Number of Status Outputs: 4
- Tube Failure Detection : Standard
- Maximum Pump Speed: 400 rpm
- Power Supply rating: 85-265V 50/60Hz 1 Phase
- Brewery
- Chemical dosing
- Food flavouring
- Mineral processing
- Pharmaceutical
- Water treatment
