Lenntech - Ozone OCS Units for Disinfection & Oxidation of Process

Modular ICT ozone generators are available in 5 g/h until 100 g/h units. The ozone production is variable between 10-100%. Feed gas is oxygen. The concentration is maximum 240 gr/m3 and nominal 135 gr/m3. The ICT generators uses the state of the art flat ceramic cell technology, which has the advantage that the ozone is produced at lower energy consumption with high ozone concentrations (up to 240 gr/m3) and compact and modular design.

Advantages

Benefits of OCS flat ceramic cell generators:

• Low energy consumption
• Reduced oxygen demand
• Compact design allows for easy build in
• Extremely quiet in operation
• Low installation and maintenance costs
• Low investment and operating costs
• High reliability

• Stainless steel skid
• Ozone Generator ICT
• Oxygen Generator
• Pump (ozone resistant) and venturi injection system
• Ambient air monitoring
• Stainless steel control cabinet with signal exchange
• Low pressure switch (water)
• Cooling water flow switch

Optional accessories:

• Ozone in water measurement
• Stainless steel piping
• Water trap
• Ozone reaction tank with degassing and ozone destructor
• Closed loop cooling water system
• Tailor made systems for your application
