Onset HOBO - Model UA-002-64 -Pendant Temperature/Light Data Logger 8K
This miniature data logger can record temperature and relative light levels. Complete with waterproof casing, this product is designed for indoor, outdoor, and underwater deployment. This model can store approximately 52,000 measurments of 10-bit readings. Use a solar radiation shield for accurate temperature measurement in sunlight. See RS1 Solar Radiation Shield (assembly required) and M-RSA (pre-assembled) Solar Radiation Shield. Note that using a solar radiation shield prevents the use of the light sensor.
Most popular related searches
data logger
solar radiation shield
radiation shielding
temperature monitoring
light sensor
temperature data logger
waterproofing
underwater monitoring
temperature indicator
temperature logger
- Low-cost temperature with alarm indication or light intensity
- Waterproof housing for wet or underwater use
- Data readout in less than 30 seconds via fast Optic USB interface
Environment:
The UA-002-64 Data Logger is for use inIndoor , Outdoor and Underwater environments
Measurements:
The UA-002-64 Data Logger supports the following measurements:
Temperature, Light Intensity, Water Temp
- Measurement range
- Temperature: -20° to 70°C (-4° to 158°F)
- Light: 0 to 320,000 lux (0 to 30,000 lumens/ft2)
- Accuracy:
- Temperature: ± 0.53°C from 0° to 50°C (± 0.95°F from 32° to 122°F)
- Light intensity: Designed for measurement of relative light levels.
- Resolution:
- Temperature: 0.14°C at 25°C (0.25°F at 77°F)
- Drift: Less than 0.1°C/year (0.2°F/year)
- Response time:
- Airflow of 2 m/s (4.4 mph): 10 minutes, typical to 90%
- Water: 5 minutes, typical to 90%
- Time accuracy: ± 1 minute per month at 25°C (77°F)
- Operating range
- In water/ice: -20° to 50°C (-4° to 122°F)
- In air: -20° to 70°C (-4° to 158°F)
- Water depth rating: 30 m from -20° to 20°C (100 ft from -4° to 68°F)
- NIST traceable certification: Available for temperature only at additional charge; temperature range -20° to 70°C (-4° to 158°F)
- Battery life: 1 year typical use
- Memory
- UA-002-08: 8K bytes (approximately 3.5K combined temperature and light readings or events)
- UA-002-64: 64K bytes (approximately 28K combined temperature and light readings or events)
- Materials: Polypropylene case; stainless steel screws; Buna-N o-ring
- Weight: 18 g (0.6 oz)
- Dimensions: 58 x 33 x 23 mm (2.3 x 1.3 x 0.9 inches)
- The CE Marking identifies this product as complying with the relevant directives in the European Union (EU).
