Perma-Shield PL - Model 431 Series -Modified Polyamine Ceramic Epoxy Coating
A 100% solids, abrasion-resistant lining specifically designed for wastewater immersion and fume environments and exposure to corrosive soils. Provides low permeation to H_2_S gas, protects against MIC and provides chemical resistance to steel, ductile iron pipe and fittings for severe wastewater or buried exposures. A coal-tar free, resin-rich formulation with low pigment volume concentration (PVC) for maximum performance.
Special Qualifications
Contains 20% ceramic microspheres for increased abrasion resistance. Compatible with high-velocity jet sewer cleaning (hydrocleaning) with 0-degree tips (Reference Technical Bulletin No. 11-86).
Meets the performance requirements of AWWA C 210 (not for potable water contact).
Carbon Steel: 30.0 to 50.0 mils (762 to 1270 microns) in one or more coats.
Ductile Iron: 40 mils (1015 microns) (nominal) in one or more coats.
Note: Number of coats and thickness requirements will vary with substrate, application method and exposure. Use Series 44-721 to increase film build. Amounts vary by kit size, refer to the Series 44-721 product data sheet. Contact your Tnemec representative for more information.
0.00 lbs/gal solids
Gloss
Self-priming, Series N69 or Series N140. Note: Series 431 must be applied to Series N69 or N140 within 7 days. Scarify the surface with fine abrasive before topcoating if exceeding this maximum recoat window.
100% (mixed)
1,604 mil sq ft/gal (39.4 m²/L at 25 microns). See APPLICATION section for coverage rates.
Number of Components
Two: Part A (amine) and Part B (epoxy)
