HQS - Model SC-L -Pet Stone Crusher (Without Ultrasound Scanner)

Impact wave source

Configure the acoustic lens electromagnetic shock wave source

Electrical parameters of the wave source

• Impact wave gravel energy level range E: 1~8 level
• It can be adjusted stepless within the range of shock wave gravel
• Pulse width 1μS; Pulse front 0.5μS
• Spot range 6.0*6.0±35mm

Ultrasound machine target system (Ultrasound Scanner is Optional)

• Ultrasound machine probe axis makes linear movement to the focus (electric) stroke 0~100mm (precision electric, not manual)
• Accurate electric control of the linear movement of Ultrasound machine probe focus (not manual)
• Ultrasound machine probe axis rings against the focus
• Ultrasound machine probe axis coincides with shock beam axis (two lines coaxis)
• Electronic automatic ranging, digital automatic display of focus distance (non-manual guessing)

Operating system (bed hanging removable)

• Touch screen displays the working parameters
• The shock wave energy is continuously adjustable
• Shock wave trigger frequency: 40~90/min
• Trigger mode: manual and continuous

Touch-screen operation

• Shock wave form real-time display
• The movements of shock wave source and treatment bed are precise electric control (not manual)

Treatment bed

• The three relative range of motion x, y, z is 100mm, 100mm and 200mm
• The maximum payload of the treatment bed is 50kg
• Exercise accuracy of the treatment bed is ≤1mm
• The treatment bed is connected with the host machine and can be moved freely

Water treatment system

• Water circulation device
• Automatic water gas removal device
