Caframo Limited
Caframo - Model BDC250 -Petite Digital Laboratory Stirrers
FromCaframo Limited
The ultimate in compact design measuring only two by four inches. The BDC250 offers great capabilities in a small package; used in formulation, R&D, clinical research, education labs, anywhere a magnetic stirrer is used. It fits into small spaces and can be easily transported to other labs or classrooms. Everything you need assembled into a complete stirring package. Included in each purchase: overhead stirrer motor, integral clamp, stainless steel collet, external power supply, grounded power cord, stand, axial and radial mixing blades, mixing shaft, manual in four languages (English, French, Spanish and German) and three year warranty.
Most popular related searches
laboratory stirrer
overhead laboratory stirrer
digital laboratory stirrer
overhead stirrer
laboratory bench
magnetic stirrer
- Speed: 50-2500 rpm
- Volume Maximum: 2 L (0.5 US Gallon)
- Viscosity Maximum: Water-like
- Torque Maximum: 10 Ncm (0.9 in-lbs = 14 in-oz)
- Output Power: 7 Watts (1/50 hp)
- Speed Display: Yes
- Speed Accuracy: ± 10 rpm or ± 3% of reading
- Torque Display: No
- Zero Torque: No
- Timer: No
- Through Shaft: No
- Collet Shaft Diameter: 6 mm (0.24 in)
- Chuck Guard: No
- Rotation Direction: Clockwise only
- Auto Start: Yes
- Housing: Chemical-resistant nylon
- Weight: Power Supply: 0.105 kg (0.23 lb), Stirrer: 0.367 kg (0.81 lb)
- IP Rating: IP42
- Voltage: 100-240 volt must use Caframo power supply
- Frequency: 50/60 Hz
- Ambient Temperature Operation: 5-40 °C (41-104 °F)
- Relative Humidity Operation: 80 %
- Stand Rod: 500 mm (19 11⁄16 in)
- Impeller Shaft Dimensions: 188 x 6.0 mm (7 ? x 0.24 in)
- Radial and Axial Blades Dimensions: 13 x 30 mm (½ x 1 3⁄16 in)
- Blade Rotation: Left hand
- Approvals: Independently tested and conforms to Canada and US standards. Power supply is CE marked and certified.
- Warranty: 3 years
- Brushless DC motor
- Digital display
- Electronic digital control
- Purchased as a complete package
- High efficiency/less heat
- Easy to use and repeatable settings
- Precise speed adjustment
- Resumes stirring at last set speed automatically when power is restored
- Everything you need for the classroom or lab bench
