PEX Everhot - 1/2 Inch x 300ft Oxygen Barrier PEX Tubing
300ft roll of 1/2` PEX Tubing with Oxygen Barrier for use in radiant heating applications. Meets/exceeds ASTM F876/877, CSA B137.5, DIN 4726 standards. Certified for use in radiant floor heating applications. UPC listed by IAPMO. PPI pressure rated at: 79psi @ 200F, 100psi @ 180F, 160psi @ 73F. Packing: Box.
Applications:
1/2" PEX Tubing with Oxygen Barrier can be used for the following radiant heating applications:
- Structural Concrete Slabs (Rebar or wire mesh reinforced, 4-6" thick). Slab-On-Grade Systems (garages, warehouses), Slab-Below-Grade Systems (basements). 1/2" PEX Tubing is secured on top of the reinforcement with wire ties, zip ties or clips.
- Non-Structural Concrete Slabs (Non-reinforced, 1.25"-2" thick). Gypsum or other thermal mass systems over subfloor. 1/2" PEX Tubing is secured to the subfloor (i.e. plywood) with plastic clips, pipe clamps or other approved fastening method.
- Below-Subfloor (Staple-up) and Above-Subfloor ("Sandwich") Systems with and without aluminum heat transfer plates.
- Sleeper-type systems (above subfloor) with and without heat transfer plates.
- Engineered Subfloors and Modular Board Systems. 1/2" PEX Tubing is secured by into grooved channels of the plywood or foam board subfloor panels.
- Copper tube finned baseboard radiators.
Compatibility:
Everhot Oxygen Barrier PEX Tubing can be installed using either Crimp type connection system (Crimp Tool, Crimp-style PEX Fittings and Copper Crimp Rings) or Clamp/Cinch type connection system (Clamp Tool, Crimp-style PEX Fittings and Stainless Steel Clamps). Also compatible with Push-Fit connection system (such as SharkBite), Viega Press type system and Compression type PEX fittings.
This product is a replacement for:
- Watts (RadiantPEX): PB032081-300
- Viega (ViegaPEX): 11425
- Zurn (ZurnPEX): QHR3PC300FX
PEX Tubing colors and packaging may vary by manufacturer.
1/2" PEX Tubing with Oxygen Barrier is the most popular size for all radiant floor heating applications due to it`s flexibility, light weight and ability to deliver large amounts of heat. According to RPA Standard Guidelines, recommended circuit length for 1/2" PEX tubing is 250-350ft, depending on the application and type of installation.
For snow melt applications, use larger PEX tubing sizes, such as 5/8" and 3/4".
