HYPER VALVES - Pilot Operated Safety Relief Valve
Size: 1" X 2” to 16” Rating: Up to 150# Pilot type: Pop action, Relief action End Connection: Flange End, Screwed end Blow Down Pressure: 10% Less Then Of The Set Pressure. Application : Air, Gas, Liquid Hydrostatic Test Pressure: 1.5 Times The Set Pressure Overpressure: 10% To 21% Of The Set Pressure Orifice Designation: As per API Material: WCB, WC1, WC6, WC9, LCB, LCC, LC3, C5, C12, CF8, CF8M, CF3, CF3M,CF8C, CN7M, CD4MCu, Inconel, Duplex steel 4A, 5A, 6A, aluminium bronze, hastelloy cMost popular related searches
safety relief valve
relief valve
pilot-operated relief valve
pilot operated safety valve
tightness testing
hydrostatic test
hydrostatic testing
hydrostatic pressure testing
air testing
- Design Standard: API 520
- Performance Standard: API 526
- Seat Tightness Test: API 527
- End Connection: Screwed To ASME B 1.20.1, Socket Weld To ASME B 16.11, Butt Weld To ASME B16.25, Flanged To ASME B 16.5
- Pilot Sensing Element
- Full Lift Pop Type Design
- Full Lift Modulating Type Design
- Stellited Nozzle & Disc Seating Area
- Floating Type Balance Seat Design
- Piston Op. Pilot Design For Pop Action
- Diaph. Op. Pilot Design For Modulating
