Fab-Seal - Plating and Metal Finishing Liner
Fab-Seal offers drop-in liners for the plating and metal finishing industry that are test proven to be the most economical way to contain these harsh chemicals.Fab-Seal drop-in liners are fabricated in our factory as a one piece unit that can be quickly installed by the customer with very little preparation. The liners are equipped with grommets around the outside of the lip for a rope that is tightened to hold it in place, or stainless clips that attach to the lip of the tank. Liners with weirs, sumps, steps, sloped floors, saddlebags are not obstacles to prevent the proper lining of a tank for you.
For larger tanks with more complicated fixtures and attachments, we offer installation by our OSHA Compliant trained technicians. Our crews are Confine Space Entry trained annually to stay up-to-date with the latest in safety procedures.
Drop-in plating and metal finishing liners provide a quick, cost effective solution for leaking steel and concrete tanks that are used for containment of anodizing, chrome plating, galvanizing, and other metal cleaning and treatment solutions. Structurally supported by tank walls, flexible, non-metallic, heavy duty Fab-Seal liners are a proven remedy for leaking tanks and secondary containment areas. Materials are available in thicknesses from 40 mil to 1875 mils. We also have materials to contain fluids up to 170 degrees F. A Chemical Resistance Chart is available upon request.
Fab-Seal can fabricate your liner with the flanged outlet in the sidewall or install the spool boot in the field in the same manner as the picture to the right. No job is too LARGE or too SMALL!
- Typical Applications : Accessories Available
- Plating Tanks : Overflow Weirs
- Rinse Tanks : Skirts
- Etching Tanks : Stainless Steel Clips
- Storage Tanks : Sumps
- Concrete Sumps : Double Bottoms
- Earthen Pits and Ponds : Leak Detectors
- Floor Areas : Patch Kits
- Concrete Trenches : Rigid PVC
- Waste Water Treatment : Batten Strips (plastic)
- Horizontal Tanks : Overflow Weirs
- Concrete Vaults : Skirts
