Real-Tech - Model S-169000 -Plug-and-Play Controller

FromUviTec, part of ABB (Formerly Real Tech Inc.)

SHARE

The plug and play Real Controller provides a simplified version of the Real Controller Pro. Featuring a character LCD display, hierarchical menu system and correlation software. A single Real Tech sensor or multiple sensors and peripheral accessory devices can easily be controlled and configured from one location. Modbus (RS485) and 4-20mA output standard. 4-20 mA input, Dry contacts, WIFI module, Modbus TCP, and cellular modem optional.

Most popular related searches

Simple to operate and control
4 line x 20 character backlit LCD
Comprehensive hierarchical menu system
Multiple sensor and accessories integration
Modbus (RS485) and 4-20mA output standard
Optional WiFi, additional 4-20 mA, modbus TCP, cell modem

Compatibility: All Real Tech sensors, except PL, GL and GA series sensors , and Real Tech accessories except for Real Pump Clean Pro.
Display: 4 line x 20 character backlit LCD with LED indicator
Operator Interface: Five push buttons to control a comprehensive hierarchical menu system
Inputs: Proprietary inputs for Real Tech sensors and accessories, and dry contact inputs standard.
Alarms: Display of sensor specific alarms
Communication: Modbus (RS485), one 4-20mA output as well as four digital inputs and four digital outputs (user configurable to dry contact or powered) are standard, digital I/O expansions, Modbus TCP, and cell modem optional.
Data Logging: Onboard. 6 month nominal (configuration dependent). Optional remote data logging. Export data via USB
Electrical: 24VDC 13.4A power adapter (accepts 90-250VAC 50/60Hz)
Enclosure: NEMA 4, wall mountable
Dimensions: 10.25”H x 10.25”W x 5.5”D
Operating Temp: 0 to 45°C (32 to 113°F)
Storage Temp: -20 to 60°C (-4 to 140°F)
Weight: 8 lb
Warranty: 2-year limited warranty
