GEMÜ - Model 410 -Pneumatically Operated Butterfly Valve

FromGEMÜ Gebrüder Müller Apparatebau GmbH & Co. KG

SHARE

The GEMÜ 410 butterfly valve is pneumatically operated. Normally Closed and Normally Open control functions are available. The valve body is available in a plastic design.

Most popular related searches

butterfly valve

pneumatic operated butterfly valve

pneumatically operated valve

pneumatic valve

Low weight
Corrosion resistant plastic body
Simple installation with union nut
Space-saving piston actuator made of plastic

Media temperature :0 to 60 °C
Ambient temperature:-10 to 60 °C
Operating pressure :0 to 6 bar
Nominal sizes:DN 15 to 50
Connection types:Union end
Connection standards:BS | DIN
Housing materials:PVC-U, grey
Liner materials:EPDM | FKM
Disc materials:PVDF
Conformities:EAC
