Polygon - Manual Butt Fusion Machine
The Polygon from McElroy is the first manual butt fusion machine that`s DataLogger® compatible. It allows installers the flexibility to complete butt and miter fusions from zero- to 45-degree angles and has the additional capability to perform socket fusions. This three-in-one machine`s simple design and light weight make it the ideal prefabrication tool on 63mm to 160mm polypropylene pipe jobsites.
The Polygon`s mitering options are designed to meet the unique complexities of mechanical piping installations and retrofits where installers must navigate around various obstructions in buildings. With the ability to perform miter fusions in the field, time and costs can be saved on purchasing and waiting on molded or fabricated fittings to be made.
Pivoting Jaws
The Polygon`s quick-clamping jaws pivot in either direction which makes the machine faster and easier to set up. The rotating jaws will lock in exact angles from zero- to 45-degrees for butt or miter fusions, and the outer jaws are easily removable for fusion in tighter work spaces. The jaws can also be swapped with an optional Spider™ 125 Adapter Kit for socket fusion.
With a manually-powered fusion carriage and a battery-operated drill to power the facer, the only power required is for the 1,600-watt heater. This helps minimize the amount of extra power equipment needed onsite and simplifies the working space.
Industry-Leading Warranty Guaranteed Performance
McElroy equipment is built to withstand the tough environments our industry encounters. We`re confident that your machine will perform to the best of its capabilities. We`ve even given each piece of equipment a 5-year warranty — the longest available in the industry.
