Lev-Co Mobi-Pulse - Model 2 - 1500 CFM - 02-006 -Portable Dual Cartridge Collector

The Mobi-Pulse 2 is an all-steel construction with high reliability and a small shop footprint. The unit is easy to use and move around, providing user-friendly operation during arm positioning and maintenance. It has a nominal airflow of 800 to 1500 CFM.

Available Options:

• Filter Options
• Hood & Nozzle Accessories
• Extraction Arms
• Preventative Maintenance Pressure Gauges
• Variable Frequency Drives
• Silencer Options

• 12, 14 &16 ga. welded steel cabinet with powder-coated finish
• Comes complete with a 10` Flexi II Extractor Arm (8" dia.) with damper
• (2) Clean2® filter cartridges (150ft² of media each)
• Manual VIBRA-PULSE® filter cleaning system
• TEFC motor
• Removable 10-gallon external dust drawer
• 8” front wheels, and 5” rear swivel casters
• Full-width handle
• Removable end cap for easy access to filter
• Removable back panel for access to the direct-drive motor/blower compartment which is wired to a side junction box.

• Complete Self Contained Unit
• Direct Drive BI Blower
• Low Center of Gravity for Easy Maneuverability and Arm Positioning
• High Reliability & Low Maintenance

Top 5 contaminants/processes/applications:

• Welding Smoke
• Grinding Dust
• Machining Dust
• Composite dust
• Fiberglass Dust

Don`t see your contaminants? Give us a call! 1-888-862-5356 or Click our instant chatbox.

IMPORTANT: For your Health and Safety, make sure to talk to an application engineer before purchasing.

MPLS2-160-2M
Mobi-Pulse 2 Filtration unit c/w (1) only 2M (7`)Flexi-I Extraction arm (6.5" dia.) with damper, (2) filter cartridges (150ft² of media each), manual VIBRA-PULSE filter cleaning system, a 1.5 Hp 115/1/60Hz TEFC motor, centrifugal blower, removable 5 gallon dust drawer, 8” front (fixed) & 5" rear (swivel) casters.

AS PER CANADIAN LAW; this unit is approved by CSA field evaluation prior to shipping in order to meet Canadian Laws and for your additional safety

MPLS2-160-3M
Mobi-Pulse 2 Filtration unit c/w (1) only 3M (10` )Flexi-I Extraction arm (6.5" dia.) with damper, (2) filter cartridges (150ft² of media each), manual VIBRA-PULSE filter cleaning system, a 1.5 Hp 115/1/60Hz TEFC motor, centrifugal blower, removable 5 gallon dust drawer, 8” front (fixed) & 5" rear (swivel) casters.

AS PER CANADIAN LAW; this unit is approved by CSA field evaluation prior to shipping in order to meet Canadian Laws and for your additional safety

MPLS2-160-4M
Mobi-Pulse 2 Filtration unit c/w (1) only 4M (14` )Flexi-I Extraction arm (6.5" dia.) with damper, (2) filter cartridges (150ft² of media each), manual VIBRA-PULSE filter cleaning system, a 1.5 Hp 115/1/60Hz TEFC motor, centrifugal blower, removable 5 gallon dust drawer, 8” front (fixed) & 5" rear (swivel) casters.

AS PER CANADIAN LAW; this unit is approved by CSA field evaluation prior to shipping in order to meet Canadian Laws and for your additional safety

MPLS2-160-5M
Mobi-Pulse 2 Filtration unit c/w (1) only 5M (17` )Flexi-I Extraction arm (6.5" dia.) with damper, (2) filter cartridges (150ft² of media each), manual VIBRA-PULSE filter cleaning system, a 1.5 Hp 115/1/60Hz TEFC motor, centrifugal blower, removable 5 gallon dust drawer, 8” front (fixed) & 5" rear (swivel) casters.

AS PER CANADIAN LAW; this unit is approved by CSA field evaluation prior to shipping in order to meet Canadian Laws and for your additional safety

MPLS2-200-2M
Mobi-Pulse 2 Filtration unit c/w (1) only 2M (7` )Flexi-II Extraction arm (8" dia.) with damper, (2) filter cartridges (150ft² of media each), manual VIBRA-PULSE filter cleaning system, a 1.5 Hp 115/1/60Hz TEFC motor, centrifugal blower, removable 5 gallon dust drawer, 8” front (fixed) & 5 rear (swivel) casters.

AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

MPLS2-200-3M
Mobi-Pulse 2 Filtration unit c/w (1) only 3M (10` )Flexi-II Extraction arm (8" dia.) with damper, (2) filter cartridges (300ft² of media each), manual VIBRA-PULSE filter cleaning system, a 1.5 Hp 115/1/60Hz TEFC motor, centrifugal blower, removable 5 gallon dust drawer, 8” front (fixed) & 5"rear (swivel) casters.

AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

MPLS2-200-4M
Mobi-Pulse 2 Filtration unit c/w (1) only 4M (14` )Flexi-II Extraction arm (8" dia.) with damper, (2) filter cartridges (300ft² of media each), manual VIBRA-PULSE filter cleaning system, a 3 Hp 115/1/60Hz TEFC motor, centrifugal blower, removable 5 gallon dust drawer, 8” front (fixed) & 5rear (swivel) casters.

AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

MPLS2-200-5M
Mobi-Pulse 2 Filtration unit c/w (1) only 5M (17` )Flexi-II Extraction arm (8" dia.) with damper, (2) filter cartridges (300 ft media each), manual VIBRA-PULSE filter cleaning system, a 5 Hp 115/1/60Hz TEFC motor, centrifugal blower, removable 5 gallon dust drawer, 8” front (fixed) & 5"rear (swivel) casters.

AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

• Filter Options (when ordering with main unit)
• Replacement Filters
• Hood & Nozzle Accessories
• Filter Options
• Preventative Maintenance Pressure Gauges (when ordering main unit)
• Variable Frequency Drives
• Silencer Option (when ordering main unit)
