OGI (Optical Gas Imaging Camera) Gasviewer - Model GV-P-3234 -Portable Infrared Gas Detection Camera
To see gas leaks invisible to the naked eyes. For fugitive emissions detection, localization, visualization, and quantification (optional). Gases appear in real time as fumes on the built-in screen. Approved as Smart LDAR Equipment in EPA method 21 and EN15446 regulations. Safe for hazardous areas.
Accuracy
Cooled detector technology allows to find leaks as low as 0,35 gr/hr for CH4 at 2 m distance
CAMERA MODES
- Color
- Infra-red
- Enhanced gas detection
RECORDING
Record your leaks picture or video on the embedded SD card. Then, download the videos through USB or Wifi to your computer.
CONNECTIVITY
- WIFI HOTSPOT: to connect an external screen, for video streaming in real time or our quantification tablet (optional).
- BLUETOOTH: to connect various measuring equipment (optional).
- GPS coordinates: to record the GPS location of each leak at the bottom of the screen.
SAFETY CERTIFICATIONS
- Ex ic nA nC IIC T6 Gc
- Ex ic IIIC T85 C Dc
- IP 65
- Very low operating costs
DETECTED GASES
400+ compounds such as: Methane, Acetic acid, Benzene, Butadiene, Butene, Butane, Dimethyl-Benzene, Ethane, Ethylene, Ethyl benzene, Ethylene oxide, Hexane, Heptane, Isobutylene, Isopropyl alcohol, Isoprene, Methanol, MEK Methyl Ethyl Ketone, Octane, Pentene, Propane, Propanol
