Vaxteel - Model PT Series -Portable Sanitation Vacuum Tank

Chassis-Mounted

• Double-Compartment 1/4" A36 Carbon Steel Vacuum Tank (split to customer specs)
• One (1) Standard Internal Anti-Surge Baffle
• Full-Length Detachable Hose Trays constructed with 12 Ga. A36 Carbon Steel
• Full-Length Rails constructed with 1/4" A36 Carbon Steel (available straight or tapered)
• Primary Shutoff: 12" Low-Profile, 1/4" Carbon Steel
• Secondary Shutoff: 10 Gallon, 1/4" Carbon Steel
• Top Manway: 20"W x 12" Neck, 1/4" Carbon Steel, 6 Wing Nut
• Rear Manway: 20"W x 12" Neck, 1/4" Carbon Steel, 5 Wing Nut
• Rear Hose Hangers, 12"
• Three (3) 5" Steel Sight Eyes
• LED Work Light Kit
• Standard Tail Light Kit
• Discharge: 4" Nipple w/ Brass Lever Valve & Aluminum Camlock Fittings
• Inlet: 3" Nipple w/ Brass Lever Valve & Aluminum Camlock Fittings
• Fresh Fill: 3" Nipple w/ 90° Elbow
• Bumble Bee Suction Hose: 2" x 25` with 2" PVC Wand & Ball Valve
• 4.5" Standard Vacuum/Pressure Gauge
• 1.5" Brass Vacuum & Pressure Relief Valves

Chassis Mounting Kit

• Bright White Urethane Paint (additional color options available)
• Slide-In Style
• Double Compartment 3/16" A36 Carbon Steel Vacuum Tank (split to customer specs)
• 2" Bumble Bee Suction Hose (25`)
• 2" PVC Wand
• 3" Fill Nipple - Top Mounted
• 3" Elbow
• 3" Camlock Fitting w/ 3" to 2" Reducer
• (2) 2" Plastic Sight Eyes (Water Comp.)
• (2) 5" Steel Sight Eyes (Waste)
• 6" Primary Shutoff w/ 3" Opening
• 2" Plastic Secondary Shutoff, 247 CFM Rating
• 2" Vertical Oil Catch Muffler, 130 CFM
• 1.5" Brass Pressure Relief Valve, 230 CFM
• 1.5" Brass Vacuum Relief Valve, 370 CFM
• 4.5" Standard Vacuum/Pressure Gauge
• 1" Brass Ball Valve - Bucket Fill
• 3" Brass Lever Valve - Discharge
• Bright White Urethane Paint (additional colors available)
