ECOM spol. s r.o. - Model 1000 ml/min ECP201L -Preparative Pump

Preparative pump with very high output pressure up to 15 MPa at flow rate of 1000 ml/min. It has two pistons connected in parallel, with diameter of 20 mm. It is suited for preparative liquid chromatography where the high pressure is needed, etc.

When working with buffered solvents, it is possible to use pistons back washing.

Pump is supported with software ECOMAC and Clarity.

• Flow rate: 2 – 1000 ml/min
• Maximum operating pressure: 15 MPa (2175.6 PSI) up to 1000 ml/min
• Flow rate setting: 1 ml/min steps
• Repeatability of flow rate adjusting: ± 1 %
• Accuracy of flow rate setting: ± 2 %
• Wetted materials: stainless steel, PEEK, Tefzel^TM, Kalrez®, ceramic, seals*
• Communication: RS232, Ethernet (LAN), USB, Remote digital I/O
• Power supply: 100-240V VAC
• Power input: 500 VA
• Dimensions (W x H x D): 276 x 153 x 620 mm (10.87 x 6.14 x 24.40 in)
• Weight: 26 kg (57.32 lb)
• Output capillary outer diameter: 1/8"
