Presto - Model 244580 -CASS Cum Salt Spray Chamber

The Presto Cass Tester has been designed strictly as per the relevant standard to assess the ability of rust proofed components to withstand corrosion due to atmospheric conditions. It is Triple Walled (with glass wool insulation).

Temperature Range : Ambient to 60 degree Celsius. (Temp. Requirement 49 +/- 2 Degree Celsius)

Temperature Accuracy: +/-1 Degree Celsius.

Temperature Control: Solid State Digital Programmable Temperature Controller cum indicator with special Zero Corrosion PT100 sensor

Air Regulator :A moisture cum oil filter and air regulator ranging from 0 to 30 psi is provided.

Construction : FRP- Fibre Reinforced Plastic

Related Standards :JISZ2371; DIN 50021; ASTM B 117; IS:5528; IS:6910; ISO:3768

Standard Facilities
All models are equipped with Air purging,Time totaliser, Cyclic timer, Regulators, Gauges and Specimen racks

• Display: HMI Based Touchscreen 7"TFT LCD Color Screen
• Chamber Temp. Range: Ambient to 60°C
• Test Chamber Temperature Range: 49°C ± 2°C
• Chamber Temperature Least Count: 0.1°C
• Chamber Temperature Repeatability: ± 1°C
• Air Saturator Temperature Range: Ambient to 65°C
• Air Saturator Temperature Least Count: 0.1 °C
• Air Saturator Temperature Repeatability: ± 2°C
• Power: 220V, Single phase, 50 Hz, 15 A
• Temperature Control: Inbuilt PID temperature Controller
• Timer (Hour meter): 6 digits
• Test Air Pressure: 0.7Kg/cm2 - 1.7Kg/cm2
• Air Regulator: 0 to 50 psi

• HMI based Touchscreen Display for ease of operation
• Inbuilt PID temperature settings for accuracy
• Corrosion Resistant PT-100 sensor
• Program profile installed for selecting test parameters of the test.
• User can create PID settings, Air Saturator settings, test temperature, test and air purge time etc.
• Live test running status can be displayed
• Robust Construction with triple walled Fiber reinforced body
• Pneumatically operated canopy"(only for 250 Ltr. Model)
• Air purge post-test for fog settlement.
• Reservoir Tank in side sponge filter equipped
• Data can be saved to USB device (Pen drive not in part of supply.)
• Set values (SV) and present values (PV) displayed together.
• Angle of Canopy designed to restrict flow of droplets directly on the test sample

New Added Features

• User can connect other devices or any computer with the test equipment using the new Ethernet technology.
• Built-in VNC server offers remote control on operations and observation of HMI based activity.This service can be used through VNC client app such as Windows, iOS, and Android.
• One can block the remote controlled operation while the test chamber is operated on-site. With a locking feature, user can stop the remote orders and allow only remote observations.
• Watch the registered test data directly on the web page feature at your systems. No installation of software required.
• Alarm notification mails will be received on your system when Logged in.This feature will notify operators for alarming situations. Also, it supports Secure Sockets Layer (SSL) protocol as per which it ensure security on data transfer.
• Equipped with 10 Pre-set timers for timing control.
• Hindi-English interchanging font feature will allow to change the language of HMI operations.
