Rainy - Model FL -Self Cleaning Roof Top Filter System

The rainwater filter is designed to accept dual intensity (both low high intensity) loads and separates the dirt particles & debris entering along with the rain water into the filter inlet through the hollow pipe based on the principle of cohesion and centrifugal force along with self cleaning mechanism.

Since the filter element assembly is an open ended system it allows for free flow. The vertically placed steel mesh does not allow the accumulation of dirt, debris and leaves inside the filter. As such the complete filter assembly has an inbuilt self cleaning mechanism whereby the water or any other solid particles do not stagnate inside the vertical filter since it has an open end leading into the drain The design, stability and filter function efficiency is directly proportional to the intensity of rainfall.  As  the  intensity  and  volume  of  rainfall  increases, greater  the  efficiency of  the  filter. However, at any given point of time, the minimum efficiency of the filter ranges from 90 to 98% from outlets which can be utilized as per the requirement. The design is fabricated in tune with the hollow pipe leading into the filter inlet of the Rooftop Filter.

• Compact in size
• Wall mounted
• SS 304 filter element
• User-friendly
• No consumables
• 250 Micron Dual intensity
• Auto flush out
• Consistent in high and log intensity of Rain
