Ranch - Model RS130 -Telemetry Units
The RS130 is an advanced cellular telemetry node, combining data logging with cellular telemetry in an integrated package also including an outdoors enclosure, solar panel, and battery. The unit is focused on ease-of-use with built-in LCD display and remote control for in-field configuration and data read-out in addition to the real-time cloud server connection. The RS130 comes in 3 models offering different cellular radio options allowing complete global footprint. It has dual analog/digital input ports, an SDI-12/RS-485 serial port, 4MB of data memory and GPS location capability.Most popular related searches
The RS130 consists of the following modular components: CPU main board, cellular radio board, and an attachment board and has the following built-in features:
- OLED display
- Infrared remote control (included)
- Li-Ion rechargeable batteries (2×2.4 AH)
- 360-degree flexible solar panel
- Advanced MPPT solar charge controller
- ARM 32 bit CPU
- 4MB flash file system for data buffering
- Internal temperature sensor
- Sensors for battery voltage, current draw, and solar charging
- 12V generator, for powering sensors that require 12V excitation
