RayClouds - Model CM-10M -Luminance Colorimeter
CM-10M Luminance Colorimeter, the best and fast brightness measurement of smart phone screen. CM-10M via probe directly measures the luminance of the product and reads the value on the LCD screen. Only prepare a portable battery and a USB cable, you can finish the luminance measurement of the product anywhere. It is ideal for fast brightness measurements of mobile phone screens.
Most popular related searches
CM-10M Colorimeter Characteristic
High Sensitive Colorimeter
- High Transmittance Filter
- High Sensitive Photo Diode
- Low Noise, High Sensitive Board Design
High Speed & High Accuracy
- Iterative Precision:±0.5%(Lv),0.001(x,y)
- Accuracy:±3%(Lv),0.003(x,y)
- (≤5cd/m2,Tack Time 0.5sec)
Dark(zero) Calibration
- Measurement Dark(Zero) automatically
- Imperviousness to temperature and humidity
Wide Iuminance Measurement Range
- 0.01cd/m2~20,000cd/m2
- fast measurement during radical change of Luminance through smart auto-gain Algorithm
Flicker Measurement
- Accurate Measurement with High Frequency
- Provide Flicker and Luminance Measurement
Spectral Characteristic
- The filter response curves are based on the CIE1931 standard
- Spectral tolerance of filter curve:≤±1%*λ
