UviTec, part of ABB (Formerly Real Tech Inc.)
Real Tech - Model C Series -Online Colour Analyzer
Real Tech’s online colour analyzer offers an affordable and accurate solution for real-time colour monitoring. Benefiting from Real Tech’s innovative Split-Sense Pro technology, the need for calibration is limited lowering maintenance requirements. Several path length options provide solutions for wastewater to high purity applications. Parameter(s): Colour.
Most popular related searches
ultraviolet disinfection performance
color analyzer
process water control
real-time analyzer
ultraviolet disinfection
water monitoring
smart water network
ultrapure water monitoring
source water monitoring
boiler feed water impurities
- Practical, accurate and affordable
- Real-time colour analysis
- Simple to install and operate
- Low maintenance, bypass style design
- 4 line x 20 character backlit LCD display
- Optional automatic chemical cleaning systems
Characteristic: Technical Data
- Path Lengths: 1 mm, 2 mm, 4 mm, 8 mm, 25 mm, 50 mm, 100 mm, 150 mm
- Parameters: Colour
- Range: Depends on model selected. Refer to range chart
- Accuracy: ± 0.5% FS
- Units: PCU, Pt-Co or HU (hazen units)
- Sampling Time: 10 seconds
- Calibration: Factory parameter calibration allows field adjustment as required.
- Cleaning: In-situ cleaning makes cleaning quick and easy. Automatic chemical cleaning is optional.
- Self-Diagnostic: Detection and diagnosis of internal system fault
- Operator Interface: Five push buttons to control a comprehensive hierarchical menu system
- Display: 4 line x 20 character backlit LCD with LED alarm indicator
- Alarms: Dry contact terminals allow for operator configurable alarms for: high and low set points, low lamp output, leak detected, system fault, etc.
- Humidity Control: Humidity sensor with large regeneratable desiccant system
- Outputs: Self-powered 4-20mA, RS232 serial for PC
- Wavelengths: Multiple visible (VIS) wavelengths. Application dependent.
- Light Source: LED
- Flow Rate: 300 - 1000 mL/min
- Pressure Rating: 20 PSI maximum
- Fluid Connections: 1/4" OD tube push-in fittings
- Electrical: 24VDC 40W power adapter (accepts 90-250VAC 50/60Hz)
- Storage Temp: -20 to 60°C (-4 to 140°F)
- Operating Temp: 0 to 45°C (32 to 113°F)
- Enclosure: NEMA 4X, wall mountable
- Weight: 22 lb (2000 series) or 24 lb (4000 series)
- Dimensions: 17”H x 14.25”W x 7.5”D (2000 series) or 17.75”H x 15.5”W x 6.75”D (4000 series)
- Warranty: 2-year limited warranty (Extended care packages available)
- Analyzer Upgrades: High Temp. Upgrade I, High Temp. Upgrade II, Cellular Modem, Dual Transmitter
* Technical Specifications are subject to change without notice.
* Water temperature range based on material compatibility only. Contact Real Tech to verify application.
