Real Tech - Model FC -Free Chlorine Analyzer

• Free chlorine, chlorine dioxide, and/or dissolved ozone

Characteristic: Technical Data

Sensor:

• Parameters: Free chlorine, chlorine dioxide, and/or dissolved ozone
• Free Chlorine Range : Selection of three measuring ranges: 0-2 mg/L , 0-20 mg/L or 0-200 mg/L
• Resolution: 0.001, 0.01 or 0.1
• Units: ppm / mg/L
• Sampling Time : 0.5 seconds
• Measurement Principle : Potentiostatic measurement technology
• Electrodes: 2 platinum rings
• Reference: Gel with annular junction
• Sensor Lifetime : Approximately 12-18 months. Depends on site and application
• Calibration: Manual correction on the selected scale and sensor’s current offset
• Cleaning: Pressurized DI water only
• Temperature Compensation: Automatic with RTD
• Flow: Constant flow required. ~150-500 mL/min
• Fluid Connections: Inlet: 1/4” fitting. Outlet: fitting for 10x14 mm tubing
• Dimensions : 5.90”H x 3.54”W x 1.57”D

Transmitter:

• Interface: Four buttons to control set-up and configuration
• Display: 1 line x 8 character LCD
• Output: Self-powered 4-20mA, RS485 serial to PC
• Electrical : 9-36 VDC
• Operating Temp: 0 to 50°C (32 to 122°F)
• Storage Temp: -10°C to 60°C (14 to 140°F)
• Weight: 5 lb
• Enclosure: IP40, wall mountable. IP65 / NEMA4 optional.
• Dimensions: 2.79”H x 3.74”W x 2.28”D (IP65/ NEMA 4 cabinet - 10.25”H x 10.25”W x 5.5”D)
• Warranty: 2-year limited warranty

* Technical Specifications are subject to change without notice.
