Real Tech - Model SP Series -Portable Multi-Wave Field Meter
The portable Multi-Wave Field Meter from Real Tech provides simple and affordable testing of organic matter in water or wastewater utilizing a tailored selection of UV and/or visible LEDs. Operation is straight forward with accurate and repeatable results obtained in seconds. An optional Battery Pack allows for sampling anywhere, anytime giving the user true portability.
-
Parameter(s): Customized to application. BOD, COD, TOC, DOC, Colour and much more
- Simple and affordable water quality testing
- Easy to use with fast 90 second warm up time
- Accurate and precise results within seconds
- Patented technology provides superior measurement performance
- No zeroing to DI water before each test
- Long lasting UV and visible LEDs
- Rugged for field testing with optional Battery Pack
- No reagents required
APPLICATIONS FOR MULTI-WAVE METER
Characteristic: Technical Data
- Path Length Options: 2 mm, 10 mm
- Parameters: Customized
- Units: mg/L
- Calibration: Calibration memory prevents the need to re-zero to DI water
- Self-Diagnostic: Notification of system failure
- Display: 4 line x 20 character backlit LCD
- Wavelengths: Multiple wavelengths
- Light Source: UV LED
- Dimensions: 8.7"L x 7.5"W x 3.9"H
- Enclosure: Rugged, compact, watertight, and dustproof
- Electrical: 12VDC 1A wall adapter (accepts 90-250VAC 50/60Hz), 12VDC car adapter
- Storage Temp: -20 to 60°C (-4 to 140°F)
- Operating Temp: 0 to 45°C (32 to 113°F)
- Weight: 4 lbs
- Technology: Split-Sense
- Warranty: 2-year limited warranty
* Technical Specifications are subject to change without notice.
* Results can not be used for compliance, only as an indicator value of organic loading for process control support.
* Liquid Ai Data Management Software is required for data and sample management, and to build site-specific calibration models to improve accuracy and reliability at any given monitoring location..
