Reimer and ProAll - Model L80-25 -Volumetric Concrete Mixers
Specification: 7.6 m3 production capacity. 50 m3/hr production rate. 5.7 m3 aggregate bin. 4.4 m3 sand bin. 2250 l water tank. 3732 kg net weight – Aluminium Body.
- Aggregate Bin Liner
- 360°SwivelChute
- Aluminium Tool Box
- Aerator System for CementBin
- Aggregate Bin Extensions
- Pneumatic Fill
- Dual Water Tank Fill
- Fly Ash Bin
- Standard System Rear Ladder & Platform
- Cement Bin Safety Rail
- Belt Materials Sensors
- Gate Height
- Verification Sensors
- Load Cell System
- Additional Vibrators
- Colour Feeder
- Fibre Feeder
- Gunite Auger
- Heat Exchanger
- Additional Admix Tanks
- Pressure Washer
- Custom Paint
- Extra Oil Cooler
- Auto-Lube System
Automated control system for mobile concrete mixers offers the following benefits:
Streamlined Operations: Eliminates the need for manual adjustments, saving time and effort during operations.
Real-timeInformation: Digital controls provide operators with immediate feedback on the mixer’s performance, enabling precise adjustments.
User-friendly Interface: The control system features an intuitive interface for easy navigation and access to critical parameters.
Data-driven Improvement:The automated control system allows operators to analyse historical information and make data-driven improvements by storing and retrieving mixing data.
Enhanced Accuracy: The automated control system ensures precise control over critical parameters, producing consistent and high-quality concrete.
This automated control system optimises operations, provides real-time feedback offers a user-friendly interface, enables data-driven improvements, and enhances accuracy for superior concrete production.
- 4 admix systems, 5 powder/auxiliary system capability
- Ability to set moisture contents
- Auger boom/ swing/ chute joystick
- Auto stow function
- Automated admix
- Automated water
- Automatic calculation of gate settings and ratios
- Calibration for aggregates and powders
- Data logging for thousands of previous mix jobs
- Digital adjustable auxiliary ratio for colour and flyash (up to 4)
- Digital adjustable cement ratio
- Digital adjustable vibrator times
- Digital auger and belt speed settings
- Digital production rate display(m3)
- Mix design loading and saving(up to 50)
- Printable receipts for last 25 jobs
- Selectable print options
- Volume stop feature
- Water set points adjusted on screen with changes in belt speed
- Water washout mode
