GF-Instruments - Model ARES II -Remote Control System

FromGF Instruments, s.r.o.

SHARE

ARES II remote controlhelps you in all cases where measuring conditions make the work difficult. You can operate ARES II system from a comfortable place with full access to the measuring parameters and to the actual results; it is possible to check the measured apparent / model section at any time during the measurement, and to remeasure its chosen part. Remote control support is a standard part of ARES II software. For the basic USB connection no additional cost is required.

Most popular related searches

radio remote control

geophysics instrument

geophysics resistivity

resistivity instrument

Wireless or line connection using radio or GSM sets, RS232 or USB connection
High operation range of distances from several meters to tens of kilometers (or worldwide)
Immediate availability of all ARES II functions
Imaging of actual apparent and model sections during measurement (2D/3D inversion)
Low cost accessories

Applications:

Time-lapse monitoring, measurement under difficult weather conditions (rain, high/low temperature), investigation of places with limited access, survey from water level.

Optional accessories:

RS232 set for remote control
Radio set for remote control
GSM set for remote control

USB connection - distance up to 3 m (using ARES II standard accessories)
RS232 connection - distance up to 1000 m
radio remote control - distance up to 10 km (the real distance is determined by field conditions)
GSM remote control - unlimited distance (local GSM coverage necessary)
Supported operating system - MS WINDOWS
Power supply for GSM and radio sets is provided from ARES II and computer units
