Rennsteig Tools, Inc.
RENNSTEIG - Model P/N 624 000 3 RT -Crimp System Tools (Hand Crimp Tool)
Tool without dies and locator, Individual parts are sold separately to suit your specific needs, This crimp tool combines full features, high precision, and top German build quality
- P/N : 624 000 3 RT : 624 000 6 RT
- Handle Type : Two-component handles
- Finish : Black-Oxide Finish : Chrome Plated
- Details :
- This crimp tool brings it all together:
- High-precision ratchet mechanism for complete crimps
- Parallel crimping performance for even crimps
- 1.2 metric tons pressure at crimping face, with minimal hand effort
- Interchangeable high-precision crimping die set
- Interchangeable locator for precision positioning of terminals
- Ensures accurate, solderless, electrical connections
- More than 400 die sets (Special locators for other contacts are available)
- Customized die sets on request
- Field Re-calibration:
- Calibration adjustment of ratchet can be accomplished in the field. See calibration and maintenance instructions packaged with the tool.
- Positive Closure:
- Ratchet requires a full closure of handles to ensure proper crimp. The ratchet release lever allows the removal of misplaced terminals.
