RiLine - Model SV 9635.000 -Compact Busbar Systems
FromRittal LLC
Board with integral busbars. Shock-hazard-protected busbar board for the safe accommodation and contacting of components, thanks to plug-in mounting. For snap-on mounting onto 35 x 7.5/15 mm busbars or for direct attachment to the mounting plate
Most popular related searches
- Material:
- Polyamide
- Polycarbonate
- E-Cu
- Fire protection corresponding to UL 94-V0
- Color: RAL 7035
- Protection category IP to IEC 60 529: IP 20
- Approvals: UL listed
- Supply includes: Integral busbars
- Number of poles: 3-pole
- Dimensions: Height: 160 mm (6.3 ˝)
- Width: 225 mm (8.9 ˝)
- Depth: 45.1 mm (1.8 ˝)
- Rated operating voltage: 690 V (AC)
- 600 V (DC)
- Size: Max. pitch units @ 45 mm: 5
- Rated current (max.): 125 A
- Packaging unit: 1 pc(s).
- Customs tariff number: 85469010
- ETIM 6.0: EC001522
- ETIM 5.0: EC001522
- eCl@ss 8.0/8.1: 27370303
- eCl@ss 7.0/7.1: 27370303
- eCl@ss 6.0/6.1: 27370303
- eCl@ss 5.1/5.1.4: 27370301
