Battery Welder Max is a high-performance, fully automated solution for welding battery modules, designed for integration into automated production lines.
The machine can be customized and optimized for welding specific products to achieve the highest efficiency.
- Machine dimensions: (LxWxH) 2350x2800x2800 mm
- Working pressure: min. 5 bar
- Machine power: 15 kW
- Weight: 3600 kg
- Axis movement speed (max.): 1500 mm/s
- Welding speed (max.): 2000 mm/s
- Work area:** max. 1200x800 mm, max. height. 300 mm
- Online monitoring of welding quality
- In-process metrology
- Full product identification - traceability
- Easy adaptation to non-standard technical requirements
- Machine design, engineering, assembly and commissioning
- Technology development and testing
- Full automation of the production process
- Professional after-sales support and service
