Scarab Magnum - Model 13 to 18* Tonne Chassis -Roadsweeper for Single‐Engine Hydrostatic Drive System
The Magnum roadsweeper is equally at home in municipal, urban or heavy duty contracting work, having been designed for mounting on truck chassis in the 13 - 18* tonne GVW range. The choice of Hydrostatic or Unidrive allows selection of the transmission and power-delivery system that best suits a user’s chassis and operational needs. The ability to combine different chassis, drive systems and water tanks ensures that the Magnum is an agile sweeper with exceptional on-task endurance.
The Magnum can be fitted to a wide choice of chassis including those from DAF, Iveco, MAN, Mercedes, Volvo, Renault, Hino and UD. For details of these and other suitable chassis specifications, please contact our sales department.
*For customers outside of the UK we can build on a Chassis over 18 tonne.
Single Engine
Scarab can justifiably claim to be the champion behind the modernday success of the truck-mounted sweeper powered from a Single Engine.
Operating the whole machine from the engine of the truck chassis provides many advantages, for example:
- Less fuel consumption
- Lower noise
- Lower engine emissions
- Less maintenance & downtime
Single Engine Hydrostatic
A Scarab designed hydrostatic gearbox is installed in the chassis driveline to exactly suit any customers’ chassis and application. Hydrostatic drive, plus a simple joystick control for Forward and Reverse, allows single-pedal control reducing fatigue and enabling the driver to fully concentrate on sweeping.
Single Engine UniDrive
The sweeping equipment is powered from a Power Take Off (PTO) fitted to the truck engine. The Magnum control system manages engine speed to ensure optimum sweeping performance. The sweeper is usually operated in a low gear for slow speed. An optional reduction gearbox is available where necessary.
Scarab’s CANbus control system has revolutionised the way sweepers are operated and maintained.
Intuitive controls and a conveniently positioned colour monitor provide comprehensive levels of feedback to both operating and service personnel.
A graphical display indicates the sweeping configuration and conditions of the vehicle systems including warnings and regular service reminders. Real-time monitoring and datalogging provides valuable assistance in resolving problems and achieving optimum machine performance.
Scarab CANbus includes universal connectors for fitment of Global positioning System (GPS) and the option of real-time data via telematic up-link.
A conveniently positioned colour monitor displays operating information in graphical form and enables the driver and service personnel to scroll through a number of screens to display and adjust vehicle set-up.
