Henan-Zhongke - Roll Crushers
This machine applies to cement, metallurgy, chemical industry, electric power, coal and other industrial sectors for crushing all kinds of medium hardness materials, such as limestone, slag, coke, coal and other materials in the debris, crushing operations.The series of roller crusher is mainly composed of roll wheel, roller bearing, pressing and adjusting device and driving device.
When the number of discharging granularity adjustment: two roller is arranged between the wedge or gasket adjusting device, wedge device is arranged on the top of the adjusting bolt, when adjusting bolt wedge to pull up, and the wedge blocks activity and at the top of the head from a fixed wheel, namely two roller gap becomes larger, the particle size becomes larger, when the wedge block down, roller on the pressing spring under the action of two wheel clearance becomes small, the particle size becomes smaller. The pad device is by increasing or decreasing the gasket or thick thin to adjust the granularity size, increase the gasket two roll wheel clearance becomes larger when reduce gasket two roll wheel clearance becomes small, the particle size becomes smaller.
Rroller crusher is mainly of Fixed Roller, Fixed roller bearing seat, Scraper device, Active Roller, Active roller bearing seat, Protection spring and hydraulic system, Bolts to fix spring, Top cover dismantling bolt, Roller observation window, Grease nipple, Machine lifting hole, Feeding inlet, Host pulley, Adjusting bolt of fixed roller, Foundation bolt hole,Bearing temperature sensor (users select the device) and so on.
- With the advanced hydraulic control system, users can adjust the pressure according to the material hardness, so that can press and pulverize the materials absolutely;
- With sensor, the machine can load relief when overload, so that to protect the machine;
- The advanced hardfaced technology improves the roller covers` life;
- Good performance, low cost in operation and easily maintainence.
