PREFA - Model DS.19 Shingle -Roof Systems
The new and innovative DS.19 shingle is not only a highlight in terms of its appearance. The new shingle can be installed on a roof pitch of 17°, thus setting new standards in this product segment. DS.19 shingle is especially light and proves itself from small surfaces right through to major projects. The fold-in-fold system ensures that DS.19 shingles are not only incredibly storm-proof and weather-proof, but also look great.
Most popular related searches
Due to their traditional appearance they are above all ideally suited to classical roof structures. Nonetheless, it can also create an interesting contrast when combined with modern architecture.
- For any project: from the smallest building to a major project
- Modern appearance and large range of colours in P.10 quality
- Can be used for roof pitches of 17° and higher
- Particularly light, storm-proof and weather-resistant
- MATERIAL: aluminium 0.7 mm thick
- VISIBLE SIDE: Coil coating
- REAR: protective paint
- SIZE: 480 × 262 mm (cover)
- WEIGHT: 1 m² = approx. 2,75 kg = 8 DS.19 shingles
- ROOF PITCH: from 17°
- INSTALLATION: from 17 to 25° you need solid sheathing; or with snow loads greater than 3.25 kN/m² (reference height for Switzerland: 925 m); or in terrain categories 0, I or II, solid sheathing with a bitumen layer is required
- FASTENING: 1 patent clip per DS.19shingle = 8 patent clips per m²
