Round Manhole Covers and Frames
Custom 8″ Diameter Manhole Frame And Cover, 3/8″ Thick Astm-A36 Carbon Steel Lay In Diamond Plate Cover, Non-Skid Surface, Ada Compliant, Rated For H-20 Wheel Loading Under 25 Mph, One (1) 1/2″ X 1″ Pick Hole For Easy Removal, 2″ Deep Heavy Duty Carbon Steel Base Flange Frame, Four (4) Gussets, Four (4) 1/2″ Anchor Holes, All Welded Construction, Painted Black Finish, Made In Usa
ALL PURPOSE ASTM-A36 CARBON STEEL ACCESS MANHOLES ARE INTENDED FOR CONCRETE, ASPHALT, GRASS OR DIRT INSTALLATION. ADA COMPLIANT DIAMOND PLATE COVER WITH NON-SKID SURFACE. RATED FOR H-20 SINGLE POINT WHEEL LOADING FOR VEHICLE TRAFFIC UNDER 25MPH. HEAVY DUTY FLAT BAR FRAME, ALL WELDED CONSTRUCTION. PAINTED BLACK FINISH. MADE IN THE USA.
Choose cover diameter, cover style, and skirt length to create your custom selection.
Diameter:
- Choose from 8″, 12″, 18″, 20″, 24″, 30″, 32″, 36″, 38″.
Frame:
- Heavy-duty frame with flat bar skirt
- Choose frame depth of 2″, 3″ 4″, 5″, 6″, 8″, 12″
Cover:
- A36 Carbon Steel Diamond Plate Cover
- Non skid surface
- H-20 wheel loading
- Cover Style:
- Lay in with pick holes or handles
- Bolt down with buna gasket and water-tight recessed handles and stainless steel hardware
Finish:
- Painted Black
- Made in the USA
