PSI - Rubber Steel Flange Gaskets

PSI - Rubber Steel Flange Gaskets

FromPSI Products GmbH

SHARE

Rubber steel gasket type G-S-S with vulcanised steel ring for greater dimensional stability, safe centring and perfect sealing according to DIN EN 1514-1 (PN6-40). Gasket according to DIN 2690, ANSI and for plastic flanges upon request. For dimensions from ND 15 up to ND 1200 (up to ND 2000 upon request). Suitable for pressure ratings PN 6 up to PN 40

Most popular related searches

flange isolating gasket

pipeline construction

construction site water

isolation gasket

Rubber-steel gasket with PTFE sleeve as a protection against chemicals

EPDM rubber qualities
EPDM service temperature: -25 °C to +120 °C
Dimensions according to DIN EN 1514-1
Applications: GRP tanks, plastic welding necks, stat. sealing systems

Low tightening torque
No retightening of flange bolts required
Even longitudinal pressing distribution on mismatched or misaligned flanges.
High resilience compensates for pressure changes and temperature fluctuations
Cost-effective due to high operational safety and low maintenance requirements
Resistant due to wide range of elastomers to choose from
Security against leakage for flanges with rough surfaces, damaged Flange gasketing surfaces as well as enamelled and rubberised flange surfaces

General pipeline construction, plant construction: water, gas, sewage, oil and chemicals.
Industry: enamelled and rubberized Pipelines
Plastic pipelines and equipment manufacturing
Mining
