WeiCe - Salt Spray (Fog) Chambers
Also known as Salt Fog Chambers, Salt Spray Cabinets, Salt Spray Test Machine, Salt Spray Testers, these chambers perform conventional salt spray tests like NSS, CASS, ASS. They meet the requirements of ASTM B 117 and similar international standards. They have been thought as the most cost-effective corrosion test solution in the market which makes your in-house tests affordable.
Five testing volumes are available which are also customizable.
- 108Ltr (3.8cu ft)
- 270Ltr (9.5cu ft)
- 576Ltr (20cu ft)
- 960Ltr (33.7cu ft)
- 1440Ltr (50.8cu ft)
Top brand components
Key components are supplied by Omron, SMC, SNS, AWIMACH and more. Excellent components extend 5+ years more life span. Click to download Componests List
Simple and easy to use/maintain
Operating by buttons, you can learn how to use within minutes. Independent components make maintenance&repair extreme convenient.
Inexpensive maintenance
Controlled by buttons, non-integrated assembly, don’t need to replace the whole thing in case of broken.
Non water jacket heating
Immersed bottom heaters raise temperature rapidly.
3rd party calibration certificate available
Upon request before ordering.
Transparent cover or window
Easy to view during testing.
Free startup consumables kit
1000g sodium chloride.
Various accessories for choice
Purge
Defog after testing.
Built-in solution reservoir
Save space.
Auto & Manual refilling system
Two refilling modes for your choice.
Patent plastic spray nozzle
Integrated filter, 4200 hours continuously work without crystallization.
Combined compressed air inlet
Combines oil & water extractor, air pressure adjustable.
High accuracy temperature sensors
PT100 titanium alloy, accuracy 0.10C.
Various sample supports
V-shaped standard PVC sample supports as standard accessories, reinforced sample support for option.
Double Protection
Lack water cut-off protection and over temperature protection as standard.
All plastic body
Air cylinder lifter
Large chamber equips air cylinder lifter.
Wet & dry bulb thermometers.
- Testing Volume: 108 L - 1440 L
- Solution Reservoir Volume: 15 L - 40 L
- Unattended Operating Days: 3 - 7 days
- Atomizing Nozzle Quantity: 1 - 2 pcs
- Cover Lifter: Available
- Bubble Tower Volume: 4 L
- Body Material: PP or PVC
- Color: Gray
- Testing Chamber Temp: Up to 60 C
- Bubble Tower Temp: Up to 70 C
- Salt Fog Collection Rate: 0.5 - 3 ml/80 cm2/H
- Spray Pressure: 0.8 - 2 kgf/cm2
- Power Source: Dependent on countries
- Defogging: Available
- Water Refilling: Manual and Automatic
- Protection: Double over-heated protection
- ISO 9227
- JIS Z 2371
- DIN 50021
- ASTM B 117
- ASTM B 368
- ASTM D 1735
- STM G 85 A1
- DEF STAN 00-35
- EN 1670
- GMW 3286
