Lenntech - Sand Filters / Anthracite ...

Lenntech - Sand Filters / Anthracite Filters

Depending on the type of water, suspended solids concentration, oil and grease, COD/ BOD, iron contents, sand filters are sized differently, but the basic design data to clarify natural waters.

Most popular related searches

sand filter

water suspended solids

suspended solids level

Filtration velocity: 6-15 m3/h.m2
Diameter: 50 cm to 1m, 1 to 3m
Filtration area: 0,2 to 0,8 m2, 0,8 to 7 m2
Flowrates: 10L/h to 10 m3/h, 10 to 100 m3/h
Pressure ratings: 4 to10 ba
Vessel Materials: Epoxy-coated steel Polyester composite, Stainless steel (on request).
Bed depth: 1 meter min.
Filtration media: Anthracite 1.4-1.5 mm, Sand 0.4-0.8 mm, Sand 1.0-2.0 mm, Gravel 2.0-3.15 mm, Gravel 3.15-5.6 mm.
Top manhole: 2 1/2 to 6", DN 400
Accessories: 5-ball or butterfly valves, 5-butterfly valves
Options: Manometers, degaser, flowmeter
Control: Automatic or manual backwash, on timer and/or differential pressure

Lenntech - Sand Filters / Anthracite Filters

Technical Data:

Sand Filters / Anthracite Filters
